Conductive Grade TPE

Find a huge selection of Conductive Grade TPE from China at Zhongsu. Provide professional after-sales service and the right price, looking forward to cooperation.

In material classification, Zhongsu Conductive Grade TPE refers to the general name of thermoplastic elastomer, and its full English name is Thermoplastic Elastomer. In actual application, TPE material refers to TPE-S, which is a polystyrene thermoplastic elastomer, which is a thermoplastic elastomer material obtained by composite modification of SEBS or SBS elastomer as the base material. TPE-S elastomers are also called TPE or TPR in the industry.

The EC series of Conductive Grade TPE by our company can be coated and injected and bonded to the surface of PC, ABS or PC/ABS products through molding processes such as secondary injection molding or two-color injection, so that the products have good hand feel and anti-slip properties. This antistatic grade material has an antistatic effect of up to 10 to the 6th power and excellent coating performance. Conductive Grade TPE is the best choice for products with antistatic requirements.


Test Item Brand No TZ-10AN TZ-20AN TZ-30AN TZ-40AN TZ-50AN TZ-60AN TZ-70AN TZ-80AN TZ-90AN TZ-100AN
Hardness (A) 10 20 30 40 50 60 70 80 90 100
Specific gravity (g/cm3) 1.006 1.036 1.046 1.07 1.057 1.06 1.068 1.077 1.089 1.077
Melt index (g/10min) 120 85.2 68 28.6 16.6 29 18.3 16.8 18 8.7
Tensile strength (MPa) 0.4 0.6 1.0 1.4 1.9 2.3 3.6 4.7 7.6 10. 1
Elongation break (%) 579 439 450 240 305 297 428 334 306 520
Tear strength (KN/m) 4 6 9 12 16 18 28 37 55 98
Applicable Temperature(℃) -40/50 -40/60 -40/60 -40/60 -40/60 -40/80 -40/80 -40/80 -40/80 -40/80
Handiness Tolerance(Shore A) +3A
Shaped Shrinkage Rate (Portrait Average) (%) 1.2%-1 .8%
Surface lesser light、matte

Conductive Grade TpeConductive Grade Tpe
