TPU Coating

High quality TPU Coating is offered by China manufacturer Zhongsu. Buy TPU Coating which is of high quality directly with low price.

Send Inquiry

Product Description

Coated TPU

As the name implies, Zhongsu high quality TPU coating is to coat TPU rubber granules on other materials. The processing methods generally used for TPU coating include one-time molding with a two-color injection molding machine, or two-time injection molding with a general injection molding machine and a coating mold.

As the name implies, TPU coating is to coat TPU rubber granules on other materials. The processing methods generally used for TPU coating are one-time molding with a two-color injection molding machine, or two-time injection molding with a general injection molding machine and a coating mold.

Coating is one of the most important molding methods or applications of TPU. Through the coating process, various functional characteristics of TPU material applications can be fully demonstrated. Such as soft touch (such as handles and hand equipment), anti-slip properties (castors, coasters, anti-slip mats, foot pads), audio, mouse, digital equipment, electronic instruments, etc., other special functions (such as kitchen utensils and daily necessities with foldable storage functions), etc.

According to the different product encapsulation structures and the required encapsulation effects, there are two different encapsulation mechanisms, commonly known as true encapsulation and false encapsulation. True encapsulation: refers to the sintering of materials at the joint surface of soft TPU and hard plastic (the position to be encapsulated).

False encapsulation:

TPU and hard plastic or other materials do not need to be achieved through the above-mentioned sintering effect. Use a suitable encapsulation structure, such as the overall encapsulation of the workpiece, or by structural treatment of the hard workpiece, such as adding holes and making some grooves on the edge of the encapsulation position, to enhance the bonding force between TPU and hard workpieces (also known as embedded injection molding).

Product features:

Comfortable feel, good encapsulation with PC and ABS, excellent mechanical properties, high wear resistance.

Products are widely used in:

Daily necessities, wearables, electronic shells, shell encapsulation, electrical foot pads, smart homes and other industries.

Project	Unit	Type Value
Polyester TPU
Hardness	Shore-A/D	55A	60A	65A	70A	75A	80A	85A	90A	95A	55D	65D	75D	85D
Specific Gravity	g/cm3	1.16	1.17	1.17	1.18	1.18	1.19	1.19	1.19	1.2	1.21	1.21	1.22	1.22
Tensile strength	MPa	15	17	22	25	32	35	40	45	50	52	55	60	60
Tensile modulus 100%	MPa	2.7	3.2	3.5	3.8	4.5	5	7	10	15	16	22	35	35
Tensile modulus 300%	MPa	4	4.5	5.5	7	8.5	12	15	24	35	38	40	43	43
Elongation at break	%	850	830	750	650	600	550	500	450	400	380	350	300	300
Tear strength	KN/mm	62	70	75	80	85	92	103	110	120	125	150	165	200
Abrasion quantity	mm3	～	～	110	97	95	90	75	65	60	56	50	45	45
Recommended melting temperature		Drying time				Drying temperature				The values in the table represent typical values only, not absolute values.
160-220℃		3H-4H				90-100℃
